MSI MEG X570S UNIFY-X MAX User Manual

18
Specifications
Continued from previous page
USB
∙ AMD® Processor
▪ 3x USB 3.2 Gen 2 10Gbps Type-A ports on the back
panel
▪ 1x USB 2.0 Type-A port on the back panel
∙ AMD® X570 Chipset
▪ 1x USB 3.2 Gen 2 10Gbps Type-C internal connector
▪ 4x USB 3.2 Gen 1 5Gbps ports available through
internal connectors
▪ 2x USB 2.0 Type-A ports on the back panel
∙ Asmedia® 3241 Chipset
▪ 1x USB 3.2 Gen 2x2 20Gbps Type-C port on the back
panel
∙ Asmedia® 1074 Chipset
▪ 4x USB 3.2 Gen 1 5Gbps Type-A port on the back panel
∙ Hub-GL850G
▪ 7x USB 2.0 ports (3 Type-A ports on the back panel, 4
ports through the internal USB 2.0 connectors)
Back Panel
Connectors
∙ 1x Clear CMOS Button
∙ 1x Flash BIOS Button
∙ 6x USB 2.0 ports
∙ 4x USB 3.2 Gen 1 5Gbps Type-A ports
∙ 3x USB 3.2 Gen 2 10Gbps Type-A ports
∙ 1x USB 3.2 Gen 2x2 20Gbps Type-C port
∙ 1x 2.5G LAN (RJ45) port
∙ 5x Audio jacks
∙ 1x Optical S/PDIF Out connector
Continued on next page

MSI MEG X570S UNIFY-X MAX Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Maximum number of SMP processors	1
Non-ECC	Yes
Memory channels	Dodeca-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	1866, 2133, 2400, 2667, 2800, 2933, 3000, 3066, 3200, 3466, 3600, 3733, 3866, 4000, 4133, 4266, 4400, 4533, 4600, 4733, 4800, 4866, 5000, 5100, 5300 MHz
RAID levels	0, 1, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, PCI Express, PCI Express 3.0, PCI Express 4.0, SATA III
Parallel processing technology support	Crossfire
Number of SATA III connectors	6
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity	0
LAN controller	Realtek RTL8125
Ethernet interface type	2.5 Gigabit Ethernet
Audio chip	Realtek ALC4080
Cooling type	Active
Component for	PC
Motherboard chipset	AMD X570
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10 x64
BIOS type	UEFI AMI
System Management BIOS (SMBIOS) version	3.4
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	244 mm
Width	305 mm
