19
Specifications
Continued from previous page
Internal Connectors
1x 24-pin ATX main power connector
2x 8-pin ATX 12V power connector
6x SATA 6Gb/s connectors
6x M.2 slots (M-Key)
1x USB 3.2 Gen 2 10Gbps Type-C port
2x USB 3.2 Gen 1 5Gbps connector (supports additional 4
USB 3.2 Gen 1 5Gbps ports)
2x USB 2.0 connectors (supports additional 4 USB 2.0
ports)
1x 4-pin CPU fan connector
1x 4-pin water-pump fan connector
6x 4-pin system fan connectors
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
1x TPM module connector
2x 2-pin Thermal Sensors connectors
1x Water Flow Meter connector
1x Tuning Controller connector
Buttons
1x Power button
1x Reset button
Jumpers
1x Clear CMOS jumper
1x Low temperature booting jumper
1x Safe Boot jumper
LED Features
1x 4-pin RGB LED connector
2x 3-pin RAINBOW LED connectors
1x 3-pin CORSAIR connector
1x 2-Digit Debug Code LED
4x EZ Debug LED
I/O Controller NUVOTON NCT6687D-R Controller Chip
Continued on next page

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the MSI MEG X570S UNIFY-X MAX and is the answer not in the manual?

MSI MEG X570S UNIFY-X MAX Specifications

General IconGeneral
Processor socketSocket AM4
Processor manufacturerAMD
Compatible processor seriesAMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Maximum number of SMP processors1
Non-ECCYes
Memory channelsDodeca-channel
Memory slots typeDIMM
Number of memory slots2
Supported memory typesDDR4-SDRAM
Maximum internal memory64 GB
Supported memory clock speeds1866, 2133, 2400, 2667, 2800, 2933, 3000, 3066, 3200, 3466, 3600, 3733, 3866, 4000, 4133, 4266, 4400, 4533, 4600, 4733, 4800, 4866, 5000, 5100, 5300 MHz
RAID levels0, 1, 10
Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2, PCI Express, PCI Express 3.0, PCI Express 4.0, SATA III
Parallel processing technology supportCrossfire
Number of SATA III connectors6
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity3
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity0
LAN controllerRealtek RTL8125
Ethernet interface type2.5 Gigabit Ethernet
Audio chipRealtek ALC4080
Cooling typeActive
Component forPC
Motherboard chipsetAMD X570
Audio output channels7.1 channels
Motherboard form factorATX
Windows operating systems supportedWindows 10 x64
BIOS typeUEFI AMI
System Management BIOS (SMBIOS) version3.4
Harmonized System (HS) code84733020
Weight and Dimensions IconWeight and Dimensions
Depth244 mm
Width305 mm
