18
Specifications
Continued from previous page
Internal Connectors
∙ 1x 24-pin ATX main power connector
∙ 2x 8-pin ATX 12V power connectors
∙ 1x 6-pin ATX PCIE power connector
∙ 6x SATA 6Gb/s connectors
∙ 3x M.2 slots (M-Key)
∙ 1x USB 3.2 Gen 2 10Gbps Type-C port
∙ 2x USB 3.2 Gen 1 5Gbps connectors (supports additional 4
USB 3.2 Gen 1 5Gbps ports)
∙ 2x USB 2.0 connectors (supports additional 4 USB 2.0
ports)
∙ 1x 4-pin CPU fan connector
∙ 1x 4-pin water-pump fan connector
∙ 8x 4-pin system fan connectors
∙ 1x 3-pin Water Flow connector
∙ 1x Front panel audio connector
∙ 2x System panel connectors
∙ 1x Chassis Intrusion connector
∙ 2x 2-pin Thermal Sensors connectors
∙ 1xTPM module connector
∙ 1x 4-pin RGB LED connector
∙ 2x 3-pin RAINBOW LED connectors
∙ 1x 3-pin CORSAIR LED connector
Internal Buttons
∙ 1x OC Retry button
∙ 1x OC Fail Save button
∙ 1x Power button
∙ 1x Reset button
Internal Pinheader
∙ 1x JBLK_U1 pinheader
∙ 1x JRATIO_U1 pinheader
Switches
∙ 1x Multi-BIOS switch
∙ 1x EZ LED Control switch
Continued on next page
