1-14
Chapter 1
1.9 Slots
AGP (Accelerated Graphics Port) Slot
The AGP slot allows you to insert the AGP graphics card. AGP is an interface
specification designed for the throughput demands of 3D graphics. It introduces a
66MHz, 32-bit channel for the graphics controller to directly access main memory and
provides 4x/8x throughputs.
PCI Slot
The PCI slot allows you to insert PCI card or TV Tuner card. When adding or
removing expansion cards, make sure that you unplug the power supply first.
Meanwhile, read the documentation for the expansion card to make any necessary
hardware or software settings.
Mini PCI
Mini PCI Slot
The motherboard provides a mini PCI slot for connecting a mini PCI interface
card.
AGPPCI
