MSI MS-7235 - Installation Guide; Specifications

En-1
Installation Guide
English
Specifications
Processor Support
- Intel
®
Pentium 4, Pentium D, Core
TM
2 series processors in LGA775 package
For the latest information about CPU, please visit http://www.msi.com.tw/program/products/mainboard/mbd/
pro_mbd_cpu_support.php
Supported FSB
- 1066/ 800/ 533 MHz
Chipset
- North Bridge: Intel
®
P965 chipset
- South Bridge: Intel
®
ICH8 chipset
Memory Support
- P965 supports 8GB at maximum.
- Supports DDRII 800/667/533 SDRAM
- 1GB DDRII 800 SDRAM memory module is not supported
- 4 DIMMs DDRII(240pin / 1.8V)
For the updated supporting memory modules, please visit http://www.msi.com.tw/program/products/
mainboard/mbd/pro_mbd_trp_list.php
LAN
- Supports PCI LAN 10/100/1000 Fast Ethernet by Realtek 8110SC
Audio
- Chip integrated by Realtek
®
AL883
- Flexible 8-channel audio with jack sensing
- Compliant with Azalia 1.0 Spec
IDE
- 1 IDE port by JMicron JMB361
- Supports Ultra DMA 66/100/133 mode
- Supports PIO, Bus Master operation mode
SATA
- 4 SATA II ports by ICH8 - 1 SATA II port by JMicron JMB361
- Supports 5 SATA II devices - Supports storage and data transfers at up to 300MB/s
Floppy
- 1 floppy port
- Supports 1 FDD with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes
Connectors
Back Panel
- 1 PS/2 mouse port - 1 PS/2 keyboard port
- 1 serial port (COM1) - 1 parallel port supporting SPP/EPP/ECP mode
- 4 USB 2.0 ports - 1 LAN jack (10/100/1000)
- 6 flexible audio jacks
On-Board Pinheaders
- 1 IrDA pinheader - 1 front audio pinheader
- 1 serial port pinheader - 3 USB 2.0 pinheaders
Slots
- 1 PCI Express x16 slot - 2 PCI Express x1 slots
- 3 PCI slots - Support 3.3V/ 5V PCI bus Interface
Form Factor
- ATX (30.5cm X 22.0cm)
Mounting
- 6 mounting holes
