Hardware Setup
MS-7596
2-5
Hardware Setup
MS-7596
Poston the coolng set onto the
retenton mechansm.
Hook one end of the clp to hook
󰘰rst.
5. Then press down the other end of the
clp to fasten the coolng set on the
top of the retenton mechansm.
Locate the Fx Lever and lft up t .
6.
Fasten down the lever.7. Attach the CPU Fan cable to the CPU
fan connector on the manboard.
8.
Important
Whle dsconnectng the Safety Hook from the 󰘰xed bolt, t s necessary to keep an eye
on your 󰘰ngers, because once the Safety Hook s dsconnected from the 󰘰xed bolt, the
󰘰xed lever wll sprng back nstantly.
