MSI MS-7623 - Memory and HT Link Configuration

En-30
MS-7623 Mainboard
Adjust CPU-NB Ratio
This item is used to adjust CPU-NB ratio.
Adjusted CPU-NB Frequency (MHz)
It shows the adjusted CPU-NB frequency. Read-only.
CPU Core Control
This item is used to control number of CPU cores. When set to [Auto], the CPU will
operate under the default number of cores. When set to [Manual], you will be able to
enable/disable the speci󰘰c CPU core.
Core 1/ 2/ 3/ 4
These items are used to enable/disable the core 1/ 2/ 3/ 4.
OC Genie Lite
Setting this item to [Enabled] allows the system to detect the maximum FSB clock and
to overclock automatically. If overclocking fails to run, you can try the lower FSB clock
for overclocking successfully.
Memory-Z
Press <Enter> to enter the sub-menu.
DIMM1~4 Memory SPD Information
Press <Enter> to enter the sub-menu. This sub-menu displays the information of
installed memory.
Advance DRAM Con󰘰guration
Press <Enter> to enter the sub-menu.
DRAM Timing Mode
Select whether DRAM timing is controlled by the SPD (Serial Presence Detect)
EEPROM on the DRAM module. Setting to [Auto] enables DRAM timings and the
following “Advance DRAM Con󰘰guration” sub-menu to be determined by BIOS based
on the con󰘰gurations on the SPD. Selecting [Manual] allows users to con󰘰gure the
DRAM timings and the following related “Advance DRAM Con󰘰guration” sub-menu
manually.
FSB/DRAM Ratio
This item allows you to select the ratio of FSB/ DRAM.
Adjusted DRAM Frequency (MHz)
It shows the adjusted Memory frequency. Read-only.
Onboard VGA Core OverClock
This item allows you to overclock the onboard VGA.
HT Link Control
Press <Enter> to enter the sub-menu.
HT Incoming/ Outgoing Link Width
These items allow you to set the Hyper-Transport Link width. Setting to [Auto], the
system will detect the HT link width automatically.
HT Link Speed
This item allows you to set the Hyper-Transport Link speed. Setting to [Auto], the sys-
tem will detect the HT link speed automatically.
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
▶
