MS-7640 Manboard
NB Phase LED
These LEDs ndcate the current North Brdge power phase mode. Follow the nstruc-
tons below to read.
Lghts O󰘯
North Brdge s n 1 phase power mode.
North Brdge s n 2 phase power mode.
CPU Phase LED panel
These LEDs ndcate the current CPU power phase mode. Follow the nstructons below
to read.
Lghts O󰘯
CPU s n 1 phase power mode.
CPU s n 2 phase power mode.
CPU s n 3 phase power mode.
CPU s n 4 phase power mode.
CPU s n 5 phase power mode.
CPU s n 6 phase power mode.
CPU s n 7 phase power mode.
CPU s n 8 phase power mode.
HDD LED
Lghts when the hard drve s operatng.
