MSI MS-7640 - Komponenten-ÜbersCht

De-4
MS-7640 Manboard
SO CKE T AM3
JPWR2, De-11
Komponenten-Überscht
Rücktafel,
De-12
CPU, De-6
CPUFAN, De-15
DDR3, De-9
SYSFAN1, De-15
JPWR1, De-11
SYSFAN2, De-15
SATA1~6, De-14
JUSB3, De-18
SYSFAN4, De-15
JTPM1, De-19
JFP1, JFP2, De-16
JBAT1, De-20
Debug-LED-Panel, De-25
JUSB1/2, De-17
POWER1, De-21
RESET1, De-21
TURBO1, De-21
JCOM1, De-19
J1394_1, De-18
JSP1, De-16
JAUD1, De-15
PCIE, De-22
PCIE, De-22
PCIE, De-22
PCI, De-22
SYSFAN3, De-15
JCI1, De-14
