Front Panel Audio Connector: FRONT_AUDIO
This connector allows you to connect the front panel audio and is compliant with Intel
®
Front Panel I/O Connectivity Design Guide.
1.MI
C L
3.MI
C R
10.Head
P
hone
Detection
5.Head P
hone
R
7.SENSE_SEN
D
9.Head P
hone
L
8.No
Pi
n
6.MI
C D
etection
4.NC
2
.Ground
OC switch /LED Connector: JFP3
This connector is for electrical connection to the overclocking switch and LED.
1
.OC
LE
D -
3
.OC
LE
D +
10.No
Pi
n
5.RS
T-
7.RS
T +
9.No
c
ontro
l
8.PWSW
+
6.PWSW
-
4
.OC
+
2
.OC
-
