MSI MS-9802 - Mainboard Specifications

MS-9802 Mainboard
2-2
Mainboard Specifications
Processor Support
- VIA C7/ Eden/ Eden ULV processor with nanoBGA2 footprint
- 3-pin CPU fan pinheader with Smart Fan Speed Control
- Power Saver
TM
Technology enabled
Supported FSB
- 400/ 533 MHz
Chipset
- Single chip solution: VIA CX700/ CX700M/ CX700M2
Memory Support
- DDR2 400/533 SDRAM (2GB Max) or ECC DDR2 400 only
- 1 DDR2 DIMM slot (240pin / 1.8V)
LAN
- 2 PCI Gb LAN by Realtek RTL8110SC
Audio
- Realtek
®
ALC888 7.1-channel HDA codec
- 6 watt amplifier
IDE
- 1 40-pin IDE connector
- Supports 2 IDE devices
CF
- 1 CF Type II socket
SATA
- 2 SATA II ports by VIA CX700/ CX700M/ CX700M2
- Supports storage and data transfers at up to 300MB/s
Expansion Slots
- 1 PCI slot
- 1 Mini PCI socket
