2-8
Hardware Setup Industrial Computer Board
GPIO Pin Header: JGPIO1
This connector is provided for the General-Purpose Input/Output (GPIO) periph-
eral module.
Serial ATA Connector: SATA1
This connector is a high-speed Serial ATA interface port. Each connector can
connect to one Serial ATA device.
Important
Please do not fold the SATA cable into a 90-degree angle. Otherwise, data loss
may occur during transmission.
