1-3
Overview
MS-98I8
Onboard Connectors
■ 1 x 4-pin DC power connector
■ 1 x 4-pin SATA power connector
■ 1 x System FAN connector
■ 1 x SATA 6Gb/s port
■ 1 x USB 2.0 connector (2 ports)
■ 1 x RS232/422/485 serial port connector
■ 3 x RS232 serial port connectors
■ 1 x Front panel connector
■ 1 x Front audio connector
■ 1 x Amplier connector
■ 1 x GPIO connector
■ 1 x LVDS connector
■ 1 x Inverter connector
■ 1 x PS/2 keyboard/mouse connector
■ 1 x LPC connector
■ 1 x Clear CMOS jumper
■ 1 x Inverter power jumper
■ 1 x LVDS power jumper
■ 1 x AT/ATX select jumper
■ 1 x COM port power jumper
Expansion Slot
■ 2 x Mini-PCIe slots (MINI_PCIE1 supports mSATA)
Form Factor
■ 146 mm x 102 mm (3.5-inch size)
Environment
■ Operating temperature: -10 ~ 60
o
C
■ Storage temperature: -20 ~ 80
o
C
■ Humidity: 10 ~ 90% RH, non-condensing
