D-6
MS-7191 M-ATX Mainboard
Display Setup
The following procedures describe display setup using Windows XP. Windows
2000/ME/9X screens are slightly different but the procedures are the same as described.
Before to enable the TV-Out function, you have to select the TV-out mode in
BIOS (refer to the “TV NTSC/PAL Display Select” item of Advance Chipset Features
for details.).
To enable the TV-Out function, follow this procedure:
2. On the next screen, click the “Wizard...” icon to open the displays manager wizard
for step-by-step assistance in setting up your display configuration.
1. After install the “ATi System Drivers” that bundled in the driver CD for the mainboard.
Restart the computer. Click the “ATI Catalyst Control Center” icon on the desktop.
click here
click here
