7. Product Specification
Product Name MSI Star Key
Chipset Broadcom BCM2045
Certification FCC, CE, DGT
Standard Bluetooth V2.0
Frequency Band 2.4~2.4835GHz unlicensed ISM band
Modulation Method GFSK, 1Mbps, 0.5BT Gaussian
Spread Spectrum FHSS (Frequency Hopping Spread Spectrum)
Transfer rates (Max) Up to 3Mbps (Max)
RF Output Power Class 1
Working distance 100m in free space
Sensitivity <-88dBm at < 0.1% BER
Antenna 2dBi Chip Antenna
Power consumption Tx Typical: 128mA
Rx Typical: 68mA
Standby Mode: 52mA
Input power DC 5V (via USB Port)
I/O Interface USB
LED indicator Power / Active
Services supported Serial Port, Dial Up Networking, Fax, Headset,
PIM Item Transfer, PIM Synchronization,
File Transfer, Network Access, Audio Gateway, HID
OS Support Windows Win 98SE / Me / 2000 / XP, Mac 10.3.5
Environment Operation temperature: 0 oC ~ + 60 oC
Storage temperature: -10 oC ~ +70 oC
Humidity: 5 ~ 90% non-condensing
Size 55(L) x 21(W) x 10(H) mm
Weight 9 g
