MSI X370 XPOWER GAMING TITANIUM

46
Onboard LEDs
Onboard LEDs
PCI_E2 LED
PCI_E4 LED
PCI_E6 LED
DIMM LEDs
These LEDs indicate the memory modules are installed.
GPU LED
This LED indicates the CPU’s iGPU is not detected and you need to install a graphics
card.
BIOS FLASHBACK+ LED
BIOS FLASHBACK+ LED indicates BIOS flash is in progress.
PCIe x16 slot LEDs
These LEDs indicate the PCIe x16 slots status.
LED Color PCIe slot status
Red x16 mode
White x8, x4, x1 mode
BIOS FLASHBACK+ LED
GPU LED
DIMM LEDs
