MSI X370 XPOWER GAMING TITANIUM

47
Onboard LEDs
LED Color Fan control mode
Red PWM mode
Green DC mode
Fan LEDs
These LEDs indicate the fan control mode.
GAME BOOST LEDs
These LEDs indicate GAME BOOST control status.
CPU_FAN1 LED
PUMP_FAN1 LED
HW GAME BOOST LED (Red)
SW GAME BOOST LED (White)
LED Color GAME BOOST control status
Red
GAME BOOST control by physical
button
White GAME BOOST control by BIOS
EZ Debug LED
These LEDs indicate the debug status of the motherboard.
CPU - indicates CPU is not detected or fail.
DRAM - indicates DRAM is not detected or fail.
VGA - indicates GPU is not detected or fail.
BOOT - indicates the booting device is not detected
or fail.
