MT Helmets ATOM 2 SV - Shield and Visor; Shield;Visor Operation; Sun Visor Operation

Atom 2 SV
27

The shield closes with an optimal airtight seal. This feature is enabled by the front button
that locks the screen.
1
Push the front button to release the shield from its sealed position allowing it to be
raised.
2
Lower the shield until you hear a click, conirming that it is sealed again.

1
Push up the side tab located on the left side of the helmet to deploy the sun visor.
2
Push down the side tab located on the left side of the helmet to retract the sun visor.
1
1
2
2
