17
Model 31AE640F352
REF.
NO.
PART
NO. DESCRIPTION
1 714-0507 Cotter Pin
2 747-0877 Rod
3 710-0599 Hex Washer Screw 1/4-20 x .5
4 784-5680 Handle Support Bracket — RH
5 784-5679 Handle Support Bracket — LH
6 748-0362 Cam Lock Handle
7 748-0363 Handle Lock Pawl
8 732-0145 Compression Spring
9 711-0653 Clevis Pin
10 720-0232 Knob
11 684-0037B Engagement Handle Assy — LH
12 784-5681 Handle Support Bracket — LH
13 784-5619A Shift Handle
14 784-5682 Handle Support Bracket — RH
15 732-0746 Torsion Spring
16 684-0036A Engagement Handle Assy — RH
17 735-0199A Rubber Bumper
18 736-0509 Washer
19 712-0271 Hex Nut 1/4-20 †
20 712-3010 Hex Nut 5/16-18
21 746-0778 Cable
22 684-0103 Panel
23 712-3068 Hex Lock Nut, 5/16-18
24 710-0449 Carriage Screw 5/16-18 x 2.25
25 712-0429 Hex Lock Nut, 5/16-18
26 714-0104 Cotter Pin
27 736-0275 Flat Washer 5/16
28 711-0677 Ferrule
29 710-0458 Carriage Screw 5/16-18 x 1.75
30 720-0274 Grip
31 749-0951 Lower Handle
32 710-1003 Hex Washer Screw
33 731-1393 Handle Panel (for top-mount lamp)
34 736-0451 Saddle Washer
35 736-0242 Bell Washer .340 ID x .872 OD
36 747-0621 Lower Shift Rod
37 726-0100 Push Cap
38 720-0201A Chute Knob
39 749-0953A Upper Handle — LH
749-0952A Upper Handle — RH
40 705-5204A Chute Crank
42 747-0697 Chute Crank Eyebolt
43 735-0234 Rubber Grommet
44 684-0008A Shift Arm Assembly
45 710-0788 Hex Washer Screw 1/4-20 x 1.0
46 784-5599 Handle Tab
47 736-0119 Lock Washer 5/16
48 710-0643 Hex Cap Screw 5/16-18 x 1
49 710-1880 Hex Cap Screw 5/16-18 x .75
50 736-0185 Flat Washer
51 731-0921 Upper Chute
52 731-1300B Lower Chute
53 712-3068 Hex Lock Nut 5/16-18
54 736-0159 5/16 Washer
55 710-0451 Carriage Bolt 5/16-18 x .75
56 710-04071 Carriage Screw 5/16-18 x 1.0
57 720-0284 Knob
58 712-3027 Hex Lock Nut 1/4-20
59 731-0851A Flange Keeper
60 710-3015 Hex Cap Screw 1/4-20 x .75
61 747-0620A Upper Shift Rod
62 750-0963 Rod Connector
63 625-0007 Halogen Light Assembly
REF.
NO.
PART
NO. DESCRIPTION
† Used with lamp ground wire
