MTD E640F User Manual

21
Models E600E, E610E, E640F & E660G
REF.
NO.
PART
NO. DESCRIPTION
1 714-0507 Cotter Pin
2 747-0877 Rod
3 710-0599 Hex Washer Screw 1/4-20 x .5
4 784-5680 Handle Support Bracket - RH
5 784-5679 Handle Support Bracket - LH
6 748-0362 Cam Lock Handle
7 748-0363 Handle Lock Pawl
8 732-0145 Compression Spring
9 711-0653 Clevis Pin
10 720-0232 Knob
11 684-0037B Handle Assy - LH
12 784-5681 Handle Support Bracket - LH
13 784-5619A Shift Handle
14 784-5682 Handle Support Bracket - RH
15 732-0746 Torsion Spring
16 684-0036A Handle Assy - RH
17 735-0199A Rubber Bumper
18 736-0509 Washer
19 736-0119 Lock Washer 5/16
20 712-3010 Hex Nut 5/16-18
21 746-0778 Cable
22 684-0103 Panel
684-0102 Panel ‡
23 712-0116 Jam Lock Nut 3/8-24
24 732-0193 Compression Spring
25 736-0105 Bell Washer
26 714-0104 Cotter Pin
27 736-0275 Flat Washer 5/16
28 711-0677 Ferrule
29 710-0459A Hex Cap Screw 3/8-24 x 1.50
30 720-0274 Grip
31 749-0911C Handle -LH
749-0910C Handle -RH (not shown)
32 710-1003 Hex Washer Screw
33 731-1391 Handle Panel
731-1393 Handle Panel w/ Top Light
34 710-0262 Carriage Bolt 5/16-18 x 1.50
35 736-0242 Bell Washer .340 ID x .872 OD
36 747-0798A Shift Rod
37 726-0100 Push Cap
38 720-0201A Chute Knob
39 715-0138 Roll Pin
40 705-5204A Chute Crank
42 747-0697 Chute Crank Eyebolt
43 735-0234 Rubber Grommet
44 684-0008A Shift Arm Assembly
45 710-0788 Hex Washer Screw 1/4-20 x 1.0
46 784-5599 Handle Tab
47 736-0119 Lock Washer 5/16
48 710-3259 Hex Cap Screw 5/16-18 x 1.75
49 710-1880 Hex Cap Screw 5/16-18 x .75
50 736-0185 Flat Washer
51 731-0921 Upper Chute
52 731-1300A Lower Chute
53 712-3068 Hex Lock Nut 5/16-18
54 736-0159 5/16 Washer
55 710-0451 Carriage Bolt 5/16-18 x .75
56 710-0276 Carriage Screw 5/16-18 x 1.0
57 720-0284 Knob
58 712-3027 Hex Lock Nut 1/4-20
59 731-0851A Flange Keeper
60 710-3015 Hex Cap Screw 1/4-20 x .75
61 725-1672 Lens Housing Assembly †
62 747-1136 Headlight Retaining Wire †
63 725-1658 Halogen Light †
64 629-0059 Light Harness †
65 731-1392 Panel w/ Light †
66 712-0271 Hex Nut 1/4-20 †
67 710-1003 Hex Washer Screw #10-16 x .625 †
68 784-5594 Chute Cable Bracket ‡
69 731-1313C Chute Tilt Cable Guide ‡
70 712-0429 Lock Nut ‡
71 710-0805 Hex Bolt 5/16-18 x 1.5” ‡
72 746-0896 Chute Control Cable ‡
73 746-0901 Chute Deflector Control Cable w/Clip ‡
74 784-5604 Chute Tilt Handle ‡
75 736-0506 Special Washer ‡
76 710-0896 AB Screw 1/4-14 x 0.625” ‡
REF.
NO.
PART
NO. DESCRIPTION
† If Equipped
‡ Chute Tilt Models only
