Ifyouhavethe42"RZTproceedasfollows:
1. Popopentheprotectivecapontheendoftheoildrainvalveto
exposethedrainport.SeeFig6-1.
50"RZT
i
Oil Drain Hose /
"_ Square=Head
"°' Hose Plug
_Oil Drain Valve
42"RZT
Figure 5=1
2. Remove the oil fill cap/dipstick from the oil fill tube.
3. Push the oil drain hose (packed with this manual) onto the
oil drain port. Route the opposite end of the hose into an
appropriate oil collection container with at least a 2.5 quart
capacity, to collect the used oil.
4. Theengineisequippedwitheitheratwist-and-pulldrain portor
a tabbed drain port. If your engine has the twist-and-pull
drain go to step a. If your engine is equipped with the
tabbed drain go to step b.
a. Turn the oil drain valve 1A-turn, then pull outward to
begin draining oil. After the oil has finished draining,
push the end of the oil drain valve back in and turn
V4-turn to secure it back in place. Re-cap the end of
the oil drain valve to keep debris from entering the
drain port.
b. Pinchthetabsontheoild rainvalve,then pulloutwardto
begin draining oil. After the oil has finished draining,
push the end of the oil drain valve back in, until the
tabs click into place. Re-cap the end of the oil drain
valve to keep debris from entering the drain port.
5. Afterthe oil hasfinished draining, push theend oftheoil drain
valve back in, until the tabs click into place. Re-cap the end
of the oil drain valve to keep debris from entering the drain
port.
6. ReplacetheoilfilterasinstructedintheKohlerOwner'sManual.
7. Refill the engine with new oil. Refer to the Kohler Owner's
Manual for information regarding the volume and weight
of engine oil.
If you have the 50" RZT proceed as follows:
1. Route the free end of the oil drain hose toward an
appropriate oil collection container with at least a 2.5 quart
capacity, to collect the used oil. Remove the oil fill cap/
dipstick from the oil fill tube.
2. While holding the free end of the oil drain hose over the oil
collection container, unscrew the square head hose plug
from the end of the hose. See Figure 6-1. Drain the engine
oil into the collection container.
NOTE:Two adjustable wrenches may be necessary to
remove the square-head hose plug. If so, place one wrench
on the square-head hose and one on the end of the hose
to loosen.
3. After draining the oil, wipe any residual oil from the oil
drain hose. Thread the square head plug into the drain
hose fitting and fully tighten the plug.
4. Replace the oil filter, and refill the engine with new oil as
instructed in the Kohler Owner's Manual.
Air Cleaner
Service the pre-cleaner and cartridge/air cleaner element as
instructed in the Kohler Owner's Manual.
SparkPlug
The spark plugs should be cleaned and the gap reset once a
season. Refer to the Kohler Owner's Manual for correct plug type
and gap specifications.
Hydrostatic Transmission
The zero turn tractor is equipped with dual integrated
hydrostatic pumps/transaxles that are sealed and are
maintenance-free. Fluid levels cannot be checked and fluid
cannot be added or changed.
GeneralBattery Information
_ WARNING!
, Should battery acid accidentally splatter into
the eyes or onto the skin, rinse the affected area
immediately with clean cold water. If there is any
further discomfort, seek prompt medical attention.
If acid spills on clothing, first dilute it with
clean water, then neutralize with a solution of
ammonia/water or baking soda/water.
NEVER connect (or disconnect) battery
charger clips to the battery while the charger is
turned on, as it can cause sparks.
Keep all sources of ignition (cigarettes,
matches, lighters) away from the battery. The gas
generated during charging can be combustible.
As a further precaution, only charge the
battery in a well ventilated area.
Always shield eyes and protect skin and
clothing when working near batteries.
Batteries contain sulfuric acid and may
emit explosive gases. Use extreme caution when
handling batteries. Keep batteries out of the reach
of children.
SECTION 6 -- MAINTENANCE & ADJUSTMENTS 23
