17
Ref. No. Part No. Description
1. 710-0654A TT Sems Screw 3/8-16 x 1.0”
2. 710-0696 Hex Bolt 3/8-24 x 0.875”
3. 710-1245B Lock Bolt 5/16-24 x 0.875”
4. — Engine
5. 736-0242 Bell Washer,.340 x.872 x.060
6. 736-0247 Flat Washer,.406ID x 1.25OD
7. 736-0331 Bell Washer,.390 x 1.13 x.062
8. 736-0505 Flat Washer,.34ID x 1.50OD
9. 736-0507 Special Washer, 1.285 x 2.0 x.119
10. 748-0360 Pulley: Adapter,.75 Dia.
11. 750-1355 Spacer,.8760ID x 1.25OD x.1900
12. 750-1356 Spacer,.8760ID x 1.25OD x.86
13. 754-04013 V-Belt, 3/8 x 21.108 Lg.
14. 754-04014 V-Belt, 3/8 x 26.680 Lg.
15. 756-04024 Auger Pulley
16. 756-0569 Pulley Half
17. 712-3000 Hex Lock Nut 3/8-16
18. 756-04035 Flat Idler
19. 738-0281 Shoulder Screw 3/8-16
20. 736-0174 Wave Washer
21. 784-0434 Auger Idler Bracket
22. 710-0520 Hex Bolt 3/8-16 x 1.50”
23. 710-0456 Screw, #10-16 x.500
24. 712-04063 Flange Lock Nut, 5/16-18
25. 790-00075 Bearing Housing
26. 732-0611 Extension Spring
27. 790-00064 Heat Shield
28. 741-0309 Ball Bearing
29. 712-04065 Flange Lock Nut, 3/8-16
30. 629-0071 Extension Cord: 110V, 3-Prong
Model 3BB
