MTD Yard Machine 31A-3AAD700 - Page 20

19
Model 3BB
Ref. No. Part No. Description
1. 684-04037 Chute Assembly
2. 710-04071 Carriage Bolt 5/16-18 x 1.0”
3. 710-0451 Carriage Bolt 5/16-18 x 0.750”
4. 712-04063 Flange Lock Nut, 5/16-18
5. 720-0284 Chute Knob Assembly
6. 731-04388A Chute Handle
7. 731-04426A Upper Chute
8. 736-0159 Washer
9. 712-04064 Flange Lock Nut, 1/4-20
10. 731-2636A Chute Adapter
11. 710-0134 Carriage Screw 1/4-20 x 0.62”
12. 731-2643 Clean-out Tool
13. 725-0157 Cable Tie
14. 731-2635 Clean-out Tool Mount
15. 731-04353 Lower Chute Ring
16. 710-0451 Carriage Bolt 5/16-18 x 0.75”
17. 731-04127 Lower Chute
18. 732-04111 Chute Adjuster Spring
19. 784-5580 Skid Shoe
20. 731-04870 Spacer, 1.25OD x.75ID x 1.00 Lg.
21. 710-0726 AB Screw 5/16-12
22. 738-04124 Shear Pin,.25 x 1.50
23. 790-00120 Shave Plate
24. 750-04191 Spacer
25. 731-04218A Impeller
26. 717-1772A Worm Shaft
27. 715-04020 Spiral Pin
28. 721-0327 Oil Seal
29. 741-0662 Flange Bearing
30. 736-3084 Flat Washer,.51 x 1.12 x.06
31. 715-04021 Spiral Pin
32. 721-0325 Plug
33. 718-04071 Thrust Collar
34. 714-04040 Bow Tie Cotter Pin
35. 741-0663 Flange Bearing
36. 714-0161 Key
37. 717-0528A Worm Gear 20T
38. 736-0351 Flat Washer
39. 684-04090 Auger Housing, 24”
40. 618-0418 Housing Ass’y LH w/Gres Ftg Hole
618-0123 Reducer Housing Assembly RH
41. 710-0642 TT Screw 1/4-20 x 0.75”
42. 618-04196 Auger Gearbox Assembly
43. 684-04113 Auger Assembly - LH
684-04114 Auger Assembly - RH
44. 790-00138 Hex Bearing Housing
45. 741-0245 Hex Flange Bearing
46. 711-04285 Auger Axle, 24”
47. 741-0493A Flange Bushing
48. 736-0351 Flat Washer
49. 737-3000 Lube Fitting
Ref. No. Part No. Description
