MTD Yard Machines 580 Series User Manual

15
Model Series 580
Ref.
No.
Part Number Description
1. 712-0267 Hex Nut, 5/16-18
2. 736-0119 Lock Washer, 5/16
3. 712-0287 Hex Nut, 1/4-20
4. 736-0329 Lock Washer, 1/4
5. 781-0095 Debris Deflector
6. 731-0725 Debris Guard
7. 781-0087 Flap Bracket, 1.12 x 5.5
8. 736-0342 Flat Washer, .283 x .75 x .030
9. 710-0252 Hex Screw w/ Nose, 1/4-20 x .85
10. 710-0751 Hex Screw, 1/4-20 x .62
11. 710-0402 Hex Screw, 5/16-18 x 4.5
12. 714-0115 Cotter Pin, 1/8 x 1.0
13. 712-0114 Slotted Hex Nut, 1/2-20
14. 736-0112 Sphere Washer, .531 x 1.6 x .045
15. 711-0386 Spacer, .38 x .50 x 3.75
16. 781-0090 Spindle Pivot Bracket Assembly
17. 715-0143 Spirol Pin, 1/4 x 1.25
18. 732-0187 Compression Spring
19. 711-0379 Shoulder Spacer, .635 x .620
20. 710-0607 Self-tapping Screw, 5/16-18 x .50
21. 736-0504 Wave Washer, .510 x .75 x .017
22. 738-0108 Shoulder Screw, .498 x 1.45
23. 734-1268 Wheel w/ Ball Bearing, 8 x 1.75
734-1781 Wheel w/ Plastic Bearing, 8 x 1.75
24. 736-0105 Spring Washer, .401 x .871 x .063
25. 712-0241 Hex Nut, 3/8-24
26. 736-0452 Bell Washer, .396 x 1.14 x .095
27. 710-0793 Round Head Bolt, 3/8-24 x .89
28. 781-1069 Front Axle Arm
29. 726-0221 Cap Speed Nut, 1/2
30. 734-1264 Wheel w/ Ball Bearing, 7 x 1.75
734-1797 Wheel w/ Plastic Bearing, 7 x 1.75
31. 714-0101 Internal Cotter Pin, .08 x 1.42
32. 738-1176 Front Axle, .50 x 7.98
33. 710-0654A Self-tapping Screw, 3/8-16 x 1.0
34. 714-0104 Internal Cotter Pin, .072 x 1.0
35. 736-0264 Flat Washer, .330 x .630 x .0635
36. 736-3050 Flat Washer, .406 x .810 x .051
37. 711-0392 Adjustment Ferrule
38. 712-0266 Center Lock Nut, 3/8-24
39. 732-0552 Curb Adjustment Lever Assembly
40. 749-0941 Support Strut, 15.91
41. 781-0075 Spindle Extension Arm
42. 738-0258 Shoulder Screw, .498 x .250
43. 736-0255 Bell Washer, .51 x 1.14 x .040
44. 736-0272 Flat Washer, .51 x 1.0 x .060
45. 750-0535 Spacer, .376 x .625 x .22
46. 736-0169 Lock Washer, 3/8
47. 712-0798 Hex Nut, 3/8-16
48. 781-0100 Curb Height Adjustment Plate
49. 720-0241 Wing Knob Assembly
50. 736-0451 Saddle Washer, .320 x .93
51. 710-1174 Carriage Bolt 5/16-18 x .75
52. 749-0666 Blade Clutch/Depth Control Lever
53. 736-0271 Spring Washer, .317 x .625 x .099
54. 710-3103 Hex Cap Screw, 5/16-18 x 2.0
55. 749-0937 Lower Handle
56. 749-0936A Upper Handle (Loop Style)
57. 781-0081 Depth Adjustment Bracket
58. 732-0369 Compression Spring, .55 x 1.37
59. 736-0204 Flat Washer, .344 x .62 x .030
60. 712-0158 Hex Lock Nut, 5/16-18
61. 720-0283 Foam Grip
62. 747-1164 Clutch Rod, 3/8 x 33.5
63. 681-0044 Edger Base
64. 720-0297 Foam Grip (Loop Handle), 20
65. 781-0091A Upper Handle Support Plate
66. 749-0938 Upper Handle (T-Style)
Ref.
No.
Part Number Description

MTD Yard Machines 580 Series Specifications

General

Brand	MTD
Model	Yard Machines 580 Series
Category	Edger
Language	English
