Current is the flow of electrons through a conductor.
The Meter's DC current ranges are 200.0mA and 10.00A；
AC current ranges are 200.0mA and 10.00A.
To measure current:
1. Turn off the power of the measured circuit. Discharge all
the high voltage capacitors.
2. Set the rotary switch to the proper range.
3. Connect the black test lead to the COM terminal and
the red test leads to the mA terminal for a maximum of
200mA. For a maximum of 10A, move the red test lead
to the 10A terminal.
4. Break the circuit path to be tested.
Connect the black test lead to the more negative side of
the break; connect the red test lead to the more positive
side of the break. (Reversing the leads will give a
negative reading, but will not damage the Meter.)
5. Turn on the power of the measured circuit, and then
read the display. Be sure to note the measurement
units at the right side of the display (mA or A). When
only the figure "1" displayed, it indicates overrange
situation and the higher range has to be selected.
6. Turn off the power of the measured circuit and discharge
all the high voltage capacitors. Remove the test leads and
recover the measured circuit.
4 TECHNICAL SPECIFICATIONS
4.1 GENERAL SPECIFICATIONS
Environment conditions:
1000V CAT. III and 600V CAT.Ⅳ
Pollution degree: 2
Altitude < 2000m
Operating temperature:
0~40℃, 32℉~122℉(<80% RH, <10℃ noncondensing)
Storage temperature:
-10~60
℃, 14℉~140℉(<70% RH, battery removed)
Temperature Coefficient:
0.1(specified accuracy) /
℃ (<18℃ or >28℃)
MAX. Voltage between terminals and earth ground:
750V AC rms or 1000V DC.
Fuse Protection: mA: fuse (FF400mA/1000V)
A: fuse (FF10A/500V)
Sample Rate: 3 times/sec for digital data.
Display: 3 1/2 digits LCD display. Automatic indication of
functions and symbols.
Over Range indication: LCD will display "1".
Low battery indication:
The " " is displayed when the battery is under the proper
operation range.
Polarity indication: "" displayed automatically.
Power source: 9V
Battery type: NEDA 1604, 6F22, or 006P.
Dimensions: 188(L)92(W)50(H) mm.
Weight: 380g. Approx. (battery included).
4.2 Measurement specifications
