Overload protection: fuse (FF400mA/1000V).
4.2.9 DC Current
Overload protection: fuse (FF400mA/1000V). 10A range fuse
(FF10A/500V)
Max. input current: 200mA dc or 200mA ac rms for mA range,
10A dc or 10A ac rms for 10A ranges.
For measurements>5A, 10 Seconds maximum ON to
measure 1 minutes OFF; Above 10A unspecified.
4.2.10 AC Current
Overload protection: fuse (FF400mA/1000V). 10A range fuse
(FF10A/500V)
Max. input current: 200mA dc or 200mA ac rms for mA range,
10A dc or 10A ac rms for 10A ranges.
For measurements>5A, 10 Seconds maximum ON to
measure 1 minutes OFF; Above 10A unspecified.
Frequency Range: 40Hz-400Hz
Response: Average, calibrated in rms of sine wave
5. MAINTENANCE
Do not attempt to repair or service your Meter unless you are
qualified to do so and have the relevant calibration,
performance test, and service information.
5.1 General Maintenance
To avoid electrical shock or damage to the meter,
do not get water inside the case. Remove the test
leads and any input signals before opening the
case
Periodically wipe the case with a damp cloth and mild
detergent. Do not use abrasives or solvents.
Dirt or moisture in the terminals can affect readings.
To clean the terminals:
Turn the meter off and remove all test leads.
Shake out any dirt that may be in the terminals.
Soak a new swab with a cleaning and oiling agent (such as
WD-40).
Work the swab around in each terminal. The oiling agent
insulates the terminals from moisture-related contamination.
5.2 Battery and Fuse replacement
To avoid false readings, which could lead to
possible electric shock or personal injury, replace
the battery as soon as the battery indicator (
)
appears.
Use only fuses with the amperage,interrutp,voltage
And speed ratings specified
FF400mA/1000V Min interrupt rating 10000A
FF10A/500V Min interrupt rating 10000A
To replace the battery or fuse:
Turn the meter off.
Disconnect test leads and/or any connectors from the
