MTS Systems Bionix User Manual

Maintenance
100 MTS Landmark™ Tabletop Load Units - Product Information
4. Turn off hydraulic pressure.
5. Use the Lock Control to unlock the crosshead position to remove pressure from the hydraulic
locks. Wait two minutes for the pressure in the locks to drop to zero before going on to the next
step.
6. Tighten each lock’s cap screw until its piston bottoms out. Then loosen and hand-tighten each
cap screw.
Item Description
1 Tighten
2 Bottom Out Position
3 Loosen, then hand tighten.
Adjusting the Hydraulic Locks
7. Loosen each of the hydraulic lock cap screws 1/4 turn.
