Dimensions
The following dimensions are rounded off to the nearest millimeter.
Item Dimensions
A 104.6 mm (4.12 in)
B 31.8 mm (1.25 in)
C 0.8 mm (0.03 in)
D 66.5 mm (2.62 in)
E 32.0 mm (1.3 in)
F 6.4 mm (0.25 in)
G 5.1 mm (0.20 in)
H Depth
Near Side: 25.4 mm (1.00 in)
Far Side: 20.3 mm (0.80 in)
I 63.5 mm (2.50 in)
Series 661 Force Transducer Dimensions
