Series 662 Force Transducers
The force transducer commonly used with the axial-torsional tabletop Series 370 Load Unit is a Series
662 Force Transducer. There is no manual for the force transducer. The following table provides the
specifications for the force transducers.
Parameter Specification
Capacity
Model 662.20HD-04
Model 662.20H-05
Axial-Torsional
15 kN (150 N·m)
25 kN (250 N·m)
Maximum excitation input 15 V DC
Bridge resistance 350Ω Axial, 700Ω Torsional
Hysteresis 0.15% of full scale
Nonlinearity 0.3% of full-scale axial, 0.15% of full-scale torsional
Temperature
Usable range
Compensated range
0.0036% of reading/°C (0.0020%/°F)
-46°C to 93°C (-50°F to 200°F)
21°C to 77°C (70°F to 170°F)
Output 1.5 mV/V at full-scale load (662.20-04)
2 mV/V at full-scale load (662.20-05)
Model Axial Load Capacity Axial-Torsional Load Capacity Thread Size
662.20H-04 15 kN 150 N·m M8 x 1.25 mm
662.20H-05 25 kN 250 N· m M10 x 1.50 mm
