Installation

58 MTS Landmark™ Tabletop Load Units - Product Information

Item Description

1 Main Power In

2 To Low Flow Solenoid

3 To Load Frame Rear Panel

4 Door Interlock Jumper (units without an enclosure)

Cable from Test Area Enclosure (units with an enclosure)

Cable from Drive Enclosure (units with an electromagnetic rotary servomotor)

Connect the Low Flow Power Supply
