16. Use torque wrench to tighten nut (3) to the specified tightening torque.
Name Size Type Lubricant Value/Standard
Nut M16 Tightening torque (Engine oil) 30 Nm +3 Nm
17. Fit gasket (10).
18. Install cover.
19. Install screws (1), washers (2) and nuts (9).
20. Tighten nuts (9).
21. Open ball valve at the inlet and outlet of the fuel treatment system.
Result: The fuel treatment system is ready for operation.
MS150063/03E 2016-02 | Fuel Supply System | 125
TIM-ID: 0000007735 - 011
