MTU 12V2000M84 - Page 35

Inclinations - standard oil system (reference: waterline)
12V2000
M84
Longitudinal inclination, continuous max. driving end down (Option: max. op-
erating inclinations)
L Degrees
(°)
15
Longitudinal inclination, temporary max. driving end down (Option: max. oper-
ating inclinations)
L Degrees
(°)
22.5
Longitudinal inclination, continuous max. driving end up (Option: max. operat-
ing inclinations)
L Degrees
(°)
0
Longitudinal inclination, temporary max., driving end up (Option: max. operat-
ing inclinations)
L Degrees
(°)
10
Transverse inclination, continuous max. (Option: max. operating inclinations) L Degrees
(°)
22.5
Transverse inclination, temporary max. (Option: max. operating inclinations) L Degrees
(°)
32.5
Capacities
12V2000
M84
Engine coolant, engine side (with cooling system) R Liters 125
Engine oil capacity, initial filling (standard oil system) (Option: max. operating
inclinations)
R Liters 123
Oil change quantity, max. (standard oil system) (Option: max. operating incli-
nations)
R Liters 113
Oil pan capacity at dipstick mark “min.” (standard oil system) (Option: max.
operating inclinations)
L Liters 87
Oil pan capacity at dipstick mark “max.” (standard oil system) (Option: max.
operating inclinations)
L Liters 105
Weights / main dimensions
12V2000
M84
Engine dry weight (with attached standard accessories, without coupling) R kg 2780
Acoustics
12V2000
M84
Exhaust noise, unsilenced - BL (free-field sound pressure level Lp, 1m dis-
tance, ISO 6798, +3dB(A) tolerance)
R dB(A) 108
Engine surface noise with attenuated intake noise (filter) - BL (free-field sound
power level Lp, 1 m distance, ISO 6798, +2dB(A) tolerance)
R dB(A) 103
MS150063/03E 2016-02 | Technical Data | 35
TIM-ID: 0000010851 - 003
