MTU 16V2000S96 - Page 129

Application Spec. value
Initial installation (new belt,
runtime 0.5-4 h)
Spec. value
(used belt, runtime 500 h)
Drive belt 1558 mm – fan Depression depth: 6 mm
Test force: 188 N
Depression depth: 5 mm
Test force: 188 N
Drive belt 1558 mm – fan (with
supplementary mass)
Depression depth: 6 mm
Test force: 188 N
Depression depth: 5 mm
Test force: 188 N
Drive belt 1522 mm – fan Depression depth: 6 mm
Test force: 188 N
Depression depth: 5 mm
Test force: 188 N
Drive belt 1707 mm – fan Depression depth: 6 mm
Test force: 188 N
Depression depth: 5 mm
Test force: 188 N
Drive belt 1665 mm – fan Depression depth: 6 mm
Test force: 188 N
Depression depth: 5 mm
Test force: 188 N
Drive belt 1623 mm – fan Depression depth: 6 mm
Test force: 188 N
Depression depth: 5 mm
Test force: 188 N
Drive belt 1854 mm – fan Depression depth: 6 mm
Test force: 188 N
Depression depth: 5 mm
Test force: 188 N
Drive belt 1800 mm – fan Depression depth: 6 mm
Test force: 188 N
Depression depth: 5 mm
Test force: 188 N
Drive belt 2008 mm – fan Depression depth: 6 mm
Test force: 188 N
Depression depth: 5 mm
Test force: 188 N
Drive belt 1971 mm – fan Depression depth: 6 mm
Test force: 188 N
Depression depth: 5 mm
Test force: 188 N
Drive belt 1936 mm – fan Depression depth: 6 mm
Test force: 188 N
Depression depth: 6 mm
Test force: 188 N
Table 3: Measuring depression depth with tension tester
Application Spec. value
Initial installation (new belt,
runtime 0.5-4 h)
Spec. value
(used belt, runtime 500 h)
Drive belt 1558 mm – fan Strand pull: 4500 N Strand pull: 3750 N
Drive belt 1558 mm – fan (with
supplementary mass)
Strand pull: 4500 N Strand pull: 3750 N
Drive belt 1522 mm – fan Strand pull: 4500 N Strand pull: 3750 N
Drive belt 1707 mm – fan Strand pull: 4500 N Strand pull: 3750 N
Drive belt 1665 mm – fan Strand pull: 4500 N Strand pull: 3750 N
Drive belt 1623 mm – fan Strand pull: 4500 N Strand pull: 3750 N
Drive belt 1854 mm – fan Strand pull: 4500 N Strand pull: 3750 N
Drive belt 1800 mm – fan Strand pull: 4500 N Strand pull: 3750 N
Drive belt 2008 mm – fan Strand pull: 4500 N Strand pull: 3750 N
Drive belt 1971 mm – fan Strand pull: 4500 N Strand pull: 3750 N
Drive belt 1936 mm – fan Strand pull: 4500 N Strand pull: 4000 N
Table 4: Measuring static belt tension
4. If the measured values deviate from the specifications above, adjust drive belt tension (→ Page 130).
5. Install protective cover.
MS150094/02E 2015-05
| Task Description | 129
TIM-ID: 0000025518 - 003
