Fault
code no. Full designation Meaning Action
Setting parame-
ter no.
315 AL Timing Cylinder B5 Time-of-flight measuring fault
injector cylinder B5: Time-of-
flight value measured ex-
tremely small or large (alarm
configuration parameter, see
PR 2.8008.100 for explana-
tion).
Replace plug-in
pump if this occurs
frequently.
1.8004.514
316 AL Timing Cylinder B6 Time-of-flight measuring fault
injector cylinder B6: Time-of-
flight value measured ex-
tremely small or large (alarm
configuration parameter, see
PR 2.8008.100 for explana-
tion).
Replace plug-in
pump if this occurs
frequently.
1.8004.515
317 AL Timing Cylinder B7 Time-of-flight measuring fault
injector cylinder B7: Time-of-
flight value measured ex-
tremely small or large (alarm
configuration parameter, see
PR 2.8008.100 for explana-
tion).
Replace plug-in
pump if this occurs
frequently.
1.8004.516
318 AL Timing Cylinder B8 Time-of-flight measuring fault
injector cylinder B8: Time-of-
flight value measured ex-
tremely small or large (alarm
configuration parameter, see
PR 2.8008.100 for explana-
tion).
Replace plug-in
pump if this occurs
frequently.
1.8004.517
319 AL Timing Cylinder B9 Time-of-flight measuring fault
injector cylinder B9: Time-of-
flight value measured ex-
tremely small or large (alarm
configuration parameter, see
PR 2.8008.100 for explana-
tion).
Replace plug-in
pump if this occurs
frequently.
1.8004.518
320 AL Timing Cylinder B10 Time-of-flight measuring fault
injector cylinder B10: Time-
of-flight value measured ex-
tremely small or large (alarm
configuration parameter, see
PR 2.8008.100 for explana-
tion).
Replace plug-in
pump if this occurs
frequently.
1.8004.519
321 AL Wiring Cylinder A1 Wiring fault in injector wiring
cylinder A1. Result: Misfiring
(alarm configuration parame-
ter, see PR 2.8008.100 for
explanation).
Check injector wir-
ing, rectify injector
solenoid valve short
circuit (positive to
negative) (e.g. by
exchanging injec-
tors). Fault rectifica-
tion: When engine is
restarted.
1.8004.520
MS15018/03E 2016-02 | Troubleshooting | 55
TIM-ID: 0000008508 - 003
