WIrInG dIaGram
Mono Block Amplifier Wiring (Single Subwoofer Load)
FUSE
1 Ohm Minimum
(THUNDER1000.1 Only)
Source Unit
Remote Signal
RCA Signal
12V
FUSE
Source Unit
Remote Signal
RCA Signal
12V
2 Ohm Minimum
