Mueller DH-5 - EH-5 Drilling Machine General Information

Feed Tube & Yoke
Collar
Ratchet Handle
Oil Hole
Clean-Out Notch
Bleeder Valve
Machine Adapter Nipple
Drill Holder
Drill
Cutting Grease
2 Double Open-end Wrench
Adjustable Wrench
MUELLER
®
DH-5 / EH-5 Drilling Machines
General Information
3
Capacity and Use
The EH-5 Drilling Machine is a hand
or power operated machine used for
drilling holes
1
/8” to 2
1
/8” inclusive,
in any size or kind of pipe (Under
certain conditions the maximum size
may be increased to 3
3
/4”.)
For complete information on the
uses of these machines and the
equipment and attachments required
for their use see the latest Mueller
Gas Catalog at muellergas.com.
Working Pressure and
Temperature Rating

Working Pressure

The working pressure or
temperature rating is reduced
accordingly if any attachment, valve,

or temperature during the drilling
operation has a maximum working
pressure or temperature rating

Equipment Furnished





 
9
/16” x
11
/16”
 
3
/4” x
13
/16”


The machine adapter, drill holder and
drill shown at right are not included
in the equipment furnished with
this machine. These items must be
ordered according to the size and
type required.
Length of Travel
EH-5 Drilling Machine has
12
1
/8
NOTE: For Operating Instructions
see pages 4 and 5. For EH-5
Drilling Machine Parts see page 7.
Machine Weight Chart
DESCRIPTION EH-5
Machine & equipment
52 lb
shipped in wooden
(23.5 kg)
storage chest

24 lb
 
eH-5 Drilling MacHine
Body Gasket
