Circuit Information
Name Circuit #1 Circuit #2 Circuit #3 Circuit #4 Circuit #5 Circuit #6 Circuit #7 Circuit #8
Number of Compressor ROs 6 0 0 0 0 0 0 0
Starting Compressor RO COMP Not Used Not Used Not Used Not Used Not Used Not Used Not Used
Part Winding? No No No No No No No No
Start Unload Bypass? No No No No No No No No
Fast Unloader? No No No No No No No No
Liquid Line Solenoid EXV & LLS None None None None None None None
Second Liquid Line? No No No No No No No No
Economizer? No No No No No No No No
Economizer Control Slide % Slide % Slide % Slide % Slide % Slide % Slide % Slide %
Number of ULS per Compressor 0 0 0 0 0 0 0 0
Loader Type Unloaders Unloaders Unloaders Unloaders Unloaders Unloaders Unloaders Unloaders
Hot Gas Bypass? None None None None None None None None
Hot Gas Reheat? No No No No No No No No
Liquid Injection? No No No No No No No No
Oil Equalization? No No No No No No No No
Mod Motor Control? No Yes No No No No No No
Low Discharge Super Heat? No No No No No No No No
External Oil Pump Option No No No No No No No No
External Oil Heater Option No No No No No No No No
Liq. Inj. on w/ Fast Unld? Not Used Not Used Not Used Not Used Not Used Not Used Not Used Not Used
Alarm Relay Not Used Not Used Not Used Not Used Not Used Not Used Not Used Not Used
Compressor Proof Not Used Not Used Not Used Not Used Not Used Not Used Not Used Not Used
Compressor Speed AO COMP % Not Used Not Used Not Used Not Used Not Used Not Used Not Used
Compressor speed fault Not Used Not Used Not Used Not Used Not Used Not Used Not Used Not Used
Pump Down Not Used Not Used Not Used Not Used Not Used Not Used Not Used Not Used
Evap EXV Output Not Used Not Used Not Used Not Used Not Used Not Used Not Used Not Used
Flow Not Used Not Used Not Used Not Used Not Used Not Used Not Used Not Used
Circuit Pump RO Not Used Not Used Not Used Not Used Not Used Not Used Not Used Not Used
IGV Open Percentage AO Not Used Not Used Not Used Not Used Not Used Not Used Not Used Not Used
Cond Fan Bank: 1 2 3 4 5 6 7 8
Coil Temp #1 ODCoilTmp Not Used Not Used Not Used Not Used Not Used Not Used Not Used
Coil Temp #2 Not Used Not Used Not Used Not Used Not Used Not Used Not Used Not Used
Tandem EXV Circuit Index 1 2 3 4 5 6 7 8
Evap EXV Control Suct Spht Suct Spht Suct Spht Suct Spht Suct Spht Suct Spht Suct Spht Suct Spht
Suction Group: 1 2 3 4 5 6 7 8
Circuit Alarm ID 1 2 3 4 5 6 7 8
Subcooler EXV AO Not Used Not Used Not Used Not Used Not Used Not Used Not Used Not Used
Subcooler Suction PSI Not Used Not Used Not Used Not Used Not Used Not Used Not Used Not Used
Subcooler Suction Temp Not Used Not Used Not Used Not Used Not Used Not Used Not Used Not Used
Subcooler Refr Level Not Used Not Used Not Used Not Used Not Used Not Used Not Used Not Used
Suction Pressure SUCT PSI Not Used Not Used Not Used Not Used Not Used Not Used Not Used
Discharge Pressure DISC PSI Not Used Not Used Not Used Not Used Not Used Not Used Not Used
Suction Temperature SUCT TMP Not Used Not Used Not Used Not Used Not Used Not Used Not Used
Circuit Information Continued on Next Page ---->
56
APPENDIX F - MHRC CONFIGURATION - CIRCUIT INFORMATION
