Multiaqua MHRC2 - APPENDIX F - Configuration

Display Units Deg F \ PSI
Default Display Key UNIT STATUS
Total Number of RO's 10
Total Number of AO's 7
Total Number of SI's 32
Total Number of RO Boards 0
Total Number of SI Boards 1
Type of I/O Boards RO-10 & SI-16-AO4
MCS-Thermostat? No
Max Lockout Resets per Day: 6
Lockout Reset SI: Not Used
Display Alarm Character(a) On Keypad LCD Screen: No
AUTH Level Bypass: Supervisor Level
History Sample Rate: 1
Activate Keypad Cursor Quick Move Feature? No
Generate Alarm for Network Time Synchronization: No
Generate Alarm When Configuration is Updated: No
Daylight Savings Time Active Yes DOW Sunday Hour 2
Spring Forward Month MAR Begin Date 8 End Date 14
Fall Back Month NOV Begin Date 1 End Date 7
RS485 Communication
MCS Network Address: 1
Protocol Type: MCS
Baud Rate: 19200
Disable Alarm Grid Pop-Up In MCS-Connect? No
Ethernet Communication
IP Adress: 192 . 168 . 100 . 10
Subnet Mask: 255 . 255 . 255 . 0
Default Gateway: 0 . 0 . 0 . 0
TCP/IP Port: 5001
BACnet Port: 47808
Extended BACnet Device ID: 18100
BACnet MV Values Start At: One
Graphic file : C://MCS/Graphics/
MAGNUM Controller Information
50
APPENDIX F - MHRC CONFIGURATION - FREQUENCY DRIVE
