Output and Input Information for Magnum
# Output Name Type # Input Name Type Digital or OffSet # AO Name
M-1 COMP Step w\ EXV M-1 C TANK TMP MCST100 0 M-1 COMP %
M-2 HotSV1A&B Standard M-2 C WTR OUT MCST100 0 M-2 EXV %
M-3 Cnd SV2A Standard M-3 H TANK TMP MCST100 0 M-3 CND FAN %
M-4 Cnd SV2B Standard M-4 H TANK OUT MCST100 0 M-4 SPAREM-4
M-5 ColdSV3 Standard M-5 SUCT PSI MCS-667 0
M-6 ColdSV4 Standard M-6 DISC PSI MCS-667 0
M-7 COND FAN Standard M-7 SUCT TMP MCST100 0
M-8 PUMP COLD Standard M-8 DISC TMP MCST100 0
M-9 PUMP HOY Standard M-9 AMPS CT-300 0
M10 ALARM Standard M10 ODCoilTmp MCST100 0
M11 L PSI OUT MCS-667 0
M12 L TEMP OUT MCST100 0
M13 HPSI MANSW DIGITAL Closed=OFF
M14 FLOW COLD DIGITAL Open=OFF
M15 FLOW HOT DIGITAL Closed=OFF
M16 RUN/STOP DIGITAL Open=OFF
1-1 SUB COOL SUBCOOL 0 1-1 COMP ENABL
1-2 HEAT MODE User Logic 0 1-2 COMP SPEED
1-3 CND OFFSET User Logic 0 1-3 VFD RESET
1-4 MB RPM MODBUS 0
1-5 MB AMPS MODBUS 0
1-6 MB PHASE MODBUS 0
1-7 MB DISCTMP MODBUS 0
1-8 MB CMP TMP MODBUS 0
1-9 SPARE1-9 SPARE 0
1-10 SPARE1-10 SPARE 0
1-11 SPARE1-11 SPARE 0
1-12 SPARE1-12 SPARE 0
1-13 SPARE1-13 SPARE 0
1-14 SPARE1-14 SPARE 0
1-15 SPARE1-15 SPARE 0
1-16 RPM CALC User Logic 0
51
APPENDIX F - MAGNUM CONTROLLER I/O
