Sensor Input Detailed Information for Magnum
Display Offset Manual Display Temp Humid Auto Circuit Select Display Filter SF SF Enable/Disable BMS_SI BMS_SI BMS_SI BMS_SI
# Sensor Name Type Value or NC/NO Text Sensor Sensor Manual Index Multiplier Divisor Offset Type (in Sec.) Low High Sensor Faults High Limit Low Limit Def Value Index
M-1 C TANK TMP MCST100 0 60 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used Not Used 0 -99.9 999.9 DISABLED Not Used Not Used Not Used Not Used
M-2 C WTR OUT MCST100 0 0 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used Not Used 0 -99.9 999.9 DISABLED Not Used Not Used Not Used Not Used
M-3 H TANK TMP MCST100 0 0 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used Not Used 0 -99.9 999.9 DISABLED Not Used Not Used Not Used Not Used
M-4 H TANK OUT MCST100 0 0 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used Not Used 0 -99.9 999.9 DISABLED Not Used Not Used Not Used Not Used
M-5 SUCT PSI MCS-667 0 0 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used Not Used 0 -99.9 999.9 DISABLED Not Used Not Used Not Used Not Used
M-6 DISC PSI MCS-667 0 0 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used Not Used 0 -99.9 999.9 DISABLED Not Used Not Used Not Used Not Used
M-7 SUCT TMP MCST100 0 0 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used Not Used 0 -99.9 999.9 DISABLED Not Used Not Used Not Used Not Used
M-8 DISC TMP MCST100 0 0 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used Not Used 0 -99.9 999.9 DISABLED Not Used Not Used Not Used Not Used
M-9 AMPS CT-300 0 0 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used Not Used 0 -99.9 999.9 DISABLED Not Used Not Used Not Used Not Used
M10 ODCoilTmp MCST100 0 0 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used Not Used 0 -99.9 999.9 DISABLED Not Used Not Used Not Used Not Used
M11 L PSI OUT MCS-667 0 0 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used Not Used 0 -99.9 999.9 DISABLED Not Used Not Used Not Used Not Used
M12 L TEMP OUT MCST100 0 0 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used Not Used 0 -99.9 999.9 DISABLED Not Used Not Used Not Used Not Used
M13 HPSI MANSW DIGITAL Not Used Closed=OFF OK/TRIP Not Used Not Used Auto Not Used Not Used Not Used Not Used Not Used 0 Not Used Not Used DISABLED Not Used Not Used Not Used Not Used
M14 FLOW COLD DIGITAL Not Used Open=OFF NO/YES Not Used Not Used Manual ON Not Used Not Used Not Used Not Used Not Used 0 Not Used Not Used DISABLED Not Used Not Used Not Used Not Used
M15 FLOW HOT DIGITAL Not Used Closed=OFF NO/YES Not Used Not Used Manual ON Not Used Not Used Not Used Not Used Not Used 0 Not Used Not Used DISABLED Not Used Not Used Not Used Not Used
M16 RUN/STOP DIGITAL Not Used Open=OFF STOP/RUN Not Used Not Used Auto Not Used Not Used Not Used Not Used Not Used 0 Not Used Not Used DISABLED Not Used Not Used Not Used Not Used
1-1 SUB COOL SUBCOOL 0 0 Not Used L TEMP OUT L PSI OUT Auto Not Used Not Used Not Used Not Used Not Used 0 -99.9 999.9 DISABLED Not Used Not Used Not Used Not Used
1-2 HEAT MODE User Logic 0 0 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used Spare 0 -999 9999 DISABLED Not Used Not Used Not Used Not Used
1-3 CND OFFSET User Logic 0 0 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used PSI GAGE 0 -99.9 999.9 DISABLED Not Used Not Used Not Used Not Used
1-4 MB RPM MODBUS 0 0 Not Used Not Used Not Used Auto Not Used 1 10 0 RPM'S 0 -999 9999 DISABLED Not Used Not Used Not Used Not Used
1-5 MB AMPS MODBUS 0 0 Not Used Not Used Not Used Auto Not Used 1 0.1 0 AMPS/CT 0 -99.9 999.9 DISABLED Not Used Not Used Not Used Not Used
1-6 MB PHASE MODBUS 0 0 Not Used Not Used Not Used Auto Not Used 1 1 0 TEMP 0 -99.9 999.9 DISABLED Not Used Not Used Not Used Not Used
1-7 MB DISCTMP MODBUS 0 0 Not Used Not Used Not Used Auto Not Used 1 10 0 Spare 0 -999 9999 DISABLED Not Used Not Used Not Used Not Used
1-8 MB CMP TMP MODBUS 0 0 Not Used Not Used Not Used Auto Not Used 1 1 0 Spare 0 -999 9999 DISABLED Not Used Not Used Not Used Not Used
1-9 SPARE1-9 SPARE 0 0 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used Not Used 0 -999 9999 DISABLED Not Used Not Used Not Used Not Used
1-10 SPARE1-10 SPARE 0 0 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used Not Used 0 -999 9999 DISABLED Not Used Not Used Not Used Not Used
1-11 SPARE1-11 SPARE 0 0 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used Not Used 0 -999 9999 DISABLED Not Used Not Used Not Used Not Used
1-12 SPARE1-12 SPARE 0 0 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used Not Used 0 -999 9999 DISABLED Not Used Not Used Not Used Not Used
1-13 SPARE1-13 SPARE 0 0 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used Not Used 0 -999 9999 DISABLED Not Used Not Used Not Used Not Used
1-14 SPARE1-14 SPARE 0 0 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used Not Used 0 -999 9999 DISABLED Not Used Not Used Not Used Not Used
1-15 SPARE1-15 SPARE 0 0 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used Not Used 0 -999 9999 DISABLED Not Used Not Used Not Used Not Used
1-16 RPM CALC User Logic 0 0 Not Used Not Used Not Used Auto Not Used Not Used Not Used Not Used RPM'S 0 -999 9999 DISABLED Not Used Not Used Not Used Not Used
52
APPENDIX F - MAGNUM CONTROLLER INPUTS
