REVISION 1
MAG V17 CHL Information
General Information
Number of Circuits: 1
Total Capacity Steps: 1
Unit Type Cooling Only
1st MOD Motor Limit: Not Used
Turbo Ice Machine: No
Lost BMS Comm.: Run
Unit Control
Run/Stop Switch: SI M16 RUN/STOP
Network Run/Stop: Not Used
Emergency Stop Switch: Not Used
Heat Control
Heat Mode Indicator Not Used
Common Reversing Valve Not Used
Unit Indicators
Warning Relay: Not Used
Alarm Output: RO M10 ALARM
Control Relay: Not Used
Lag On/Off RO: Not Used
Unit Status Relay: Not Used
Unit Power
Phase Loss: Not Used
Voltage A: Not Used
Voltage B: Not Used
Voltage C: Not Used
Amps A: SI 3-9 SPARE3-9
Unit KW: Not Used
Unit Sensors
Smoke Indicator: Not Used
Enthalpy Sensor: Not Used
Ambient Temperature: Not Used
Ambient Humidity: Not Used
Demand Limit FLA%: Not Used
Demand Limit Steps: Not Used
Vestibule Control
Temp Control Sensor: Not Used
Fan Relay: Not Used
Cooling Relay: Not Used
Heating Relay: Not Used
Compressor Information
Compressor Type: VFD Scroll
Keep Running Comp. at 100% when Starting next? No
Unload Compressor before Starting next? 0 Seconds
Fast unload Delay? 30 Seconds
Minimum Delay between Comp. starts? 120 Seconds
Pre-Pumpout? Yes
Last Stage to 100% (Override Setpoint)? No
Lube State Oil Setpoint? Actual Temp Value
Oil Heater Control Setpoint? Actual Temp Value
Rotate On? Run Time
Vane Control Method Compressor FLA%
Wanted FLA-Starting Next Comp. Use Min FLA-(Stpt #31)
Control of Oil Pump Pump Always On
