Evaporator Information
Capacity Control
Control Method: Control Zone
Control Temperature On: Leaving Temp
Entering Temperature: SI M-3 H TANK TMP
Leaving Temperature: SI M-1 C TANK TMP
Target Reset: Normal AI 0-5 Volts
Target (SP #1) Reset: Not Used
Refrigerant Type: R410A
Pump/Fan
Flow Switch A: SI M14 FLOW COLD
Pump/Fan #1A: RO M-8 PUMP COLD
Pump/Fan #2A: Not Used
Flow Switch B: SI M15 FLOW HOT
Pump/Fan #1B: RO M-9 SPARE5-7
Pump/Fan #2B: Not Used
Circuit Valve/Pump Control
Force One Always On? No
Process Control
Process Output Type is Modulating (AO)
Process Pump Relay #1: Not Used
Process Pump Relay #2: Not Used
Process Control Type is VFD
VFD Speed AO #1: Not Used
VFD Speed AO #2: Not Used
Pressure SI IN #1: Not Used
Pressure SI IN #2: Not Used
Pressure SI OUT #1: Not Used
Pressure SI OUT #2: Not Used
VFD Fault #1: Not Used
VFD Fault #2: Not Used
Evap Tonnage: Not Used
Heat Control
Defrost Type: Reverse Cycle
Barrel Heater Relay: Not Used
Reheat Control: Not Used
Condenser Information
Condenser Type: Modulating Step Common
Starting Condenser Relay: RO M-7 COND FAN
Number of Condenser Stages: 1
Fan AO: AO M-3 CND FAN %
AO Starting Stage: 1
Condenser Starting Fault: Not Used
Number of Condenser Faults: 0
Sump Temperature: Not Used
Condenser Reset: SI 1-3 CND OFFSET
Control Condenser On: Disc PSI
Fluid Cooler Economizer? No
Newly Started Comp Controls Common Fan Bank No
Default Analog Output % When Compressor is OFF 0%
Start Control on Analog Output: Below, But Near, Control Zone
54
APPENDIX F - MAGNUM MHRC CONFIGURATION
