multicomp pro MP720783 - Arbitrary Waveform Generator （ (Optional)

34
Basic
function
Range
Minimum
resolution
Accuracy
Ma function: self-healing fuse 400 mA/250 V; Ampere function:
10A/600 V, D5.2*20, fast-acting fuse
Resistance
200.00Ω
0.01Ω
±(0.8%+3dig)
2.0000kΩ
0.1Ω
20.000kΩ
1Ω
200.00kΩ
10Ω
2.0000MΩ
100Ω
20.000MΩ
1kΩ
±(1%+3dig)
100.00MΩ
10kΩ
±(3%+3dig)
Capacitance
20.000nF
1pF
±(3.0%+10dig)
200.00nF
10pF
2.0000μF
100pF
20.000μF
1nF
200.00μF
10nF
2.0000mF
100nF
Others
On/Off test
√ (<50Ω)
Diode test
√(<0-2V)
Auto range
√
TRMS
√
Arbitrary Waveform Generator (MP720781 & MP720783)
Characteristics
Description
Waveform Frequency
Sine
0.1Hz~25MHz
Square
0.1Hz~5MHz
Ramp
0.1Hz~1MHz
Pulse
0.1Hz~5MHz
EXP
0.1Hz~5MHz
Sampling
125MSa/s
Amplitude(50Ω)
0.01Vpp ~ 2.5Vpp
DC offset(High Z)
±(2.5V – Amplitude Vpp/2)
Frequency Resolution
0.01%
Channel
1
Waveform Depth
8k
Vertical Resolution
14 bit
Output Impedance
50 Ω
