Page <8> V1.012/10/22
Newark.com/multicomp-pro
Farnell.com/multicomp-pro
sg.element14.com/b/multicomp-pro
AC Voltage/Voltage Frequency
Range
Resolution Accuracy
MP60607 MP60608
4.000V 6.000V 0.001V ±(1 +5)
40.00V 60.00V 0.01V
±(0.8 +5)400.0V 600.0V 0.1V
600V - 1V
Voltage Frequency
10Hz~60KHz
0.01Hz~0.01kHz ±(0.5%+2)
Caution:
• MP60607: short press “SELECT” in AC voltage/Hz scale to enter the Hz Function;
MP60608: long press “SELECT” to enter/exit the Hz function, the input range over 5V.
• The input impedance is about 10MΩ
• Current/voltage frequency response: 45Hz ~ 400Hz, displays true RMS value
• Accuracy guarantee range: 1%~100%
• AC crest factor of non-sinusoidal wave can reach 3.0 at 4000 counts while can only reach 1.8 at 6000 counts, the addi-
tional error should be added for the corresponding crest factor as follows:
A. Add 3% when the peak factor is 1 ~ 2
B. Add 5% when the peak factor is 2 ~ 2.5
C. Add 7% when the peak factor is 2.5 ~ 3
11.3 Continuity/Diode Measurement
Function Range Resolution Accuracy
400.0Ω/600.0Ω 0.1Ω
≤10Ω: Consecutive beeps
≥31Ω: No beep
The median: uncertain
4.000V/6.000V 0.001V
The open circuit voltage is about 4V
For the silicon PN junction diode, the
voltage value is generally about 0.5~0.8V.
11.4 Resistance Measurement
Range
Resolution Accuracy
MP60607 MP60608
400.0Ω 600.0Ω 0.1Ω ±(1 +2)
4.000kΩ 6.000kΩ 0.001kΩ
±(0.8 +2)40.00kΩ 60.00kΩ 0.01kΩ
400.0kΩ 600.0kΩ 0.1kΩ
4.000MΩ 6.000MΩ 0.001MΩ
±(2.5% +5)
40.00MΩ 60.00MΩ 0.01MΩ
Caution:
• Measured resistance value = displayed value – resistance value of short circuit tested leads
• Open circuit voltage is about 1V
• Overload protection: 600Vrms
