AC Clamp-on Meter Model CM 660 / CM 670 / CM 685 19
4.6 Frequency Measuring Using Current Input
20 to 4000Hz (2 ranges)
• Turn the rotary switch to the range
• Press the SELECT button to measure the frequency ( will
appear on the display)
• Clamp the jaws around the conductor to be measured
• Press the SELECT button to display the current
Warning: “-----” indicates that A <2A and F <20Hz
TM
CM 660
CAT III
HOLD
600V
COM
Hz
OFF
SELECT RANGE MIN/MAX PEAK
OFF
TEMP.
Hz
V
MAX
