AC Clamp-on Meter Model CM 660 / CM 670 / CM 685

4.7 Frequency Measuring Using Voltage Input

20 to 4000Hz (2 ranges)

• Turn the rotary switch to the range

• Press the SELECT button to measure the frequency (

will

appear on the display)

• Insert the black lead to the black "COM" input jack and the red

lead to the red “+” input jack

• Bring the test probe tips into contact with the sample under test

• Press the SELECT button to display the voltage

Warning:

“-----” indicates that V <0.2V and F <20Hz

CM 660

CAT III

HOLD

600V

COM

OFF

SELECT RANGE MIN/MAX PEAK

OFF

TEMP.

MAX
