QUICK START GUIDE
1. Remove the semi-transparent cap from the Datalogger.
2. Install the battery in the Datalogger. If battery has been
installed, you’d better make sure the battery in the Datalogger
is sufficient to finish your task. For more details, see USER’S
GUIDE.
3. Insert the Datalogger into a free USB port on your computer.
The computer will automatically detect the presence of the
Datalogger and start the hardware installation process.
4. Double-click the Datalogger icon on your desktop to launch
the graph software. You will see the Main Screen.
5. Set up and start the Data Logger and follow the setup
procedure:
-Select the Start Mode
-Enter the Logger Name
-Select the Sample Point
-Select the LED Flash Cycle
-Confirm whether LEDs flash when the logging exceed the
configured alarm level.
-Select the Unit for Temperature.
-Enter Low Alarm and High Alarm for Temperature and
Relative Humidity.
-Then click the Setup button
6. The summary screen will appear.
7. Remove the Logger from the computer and place it in the
location where you want to measure temperature.
Notes: When the Logger is connected to the USB port, the battery
inside the Data Logger is discharged at a higher rate than normal.
To conserve battery life, do not leave the Logger connected to the
USB port for a prolonged period of time.
