LOGGING READINGS
If INSTANT was selected in the SETUP window, the Logger begins
logging at the instant the SETUP button is pressed. If MANUAL was
selected, the Logger must be manually started by pressing and
holding the Logger’s yellow button for approx. 3 seconds or until the
two LEDs on the Logger flash at the same time.
Logging will continue at the programmed sample rate until the
number of readings (sample points) specified in the Setup window
is reached.
The green LED flashes once per sample point and the red or yellow
LED flashes when user programmed alarm limits are exceeded. For
details, see LED status guide.
DOWNLOAD READINGS TO PC
To transfer the readings stored in the Logger to the PC:
1. Connect the Logger to the same USB port used when the
Logger was initialised
2. Open the Datalogger software program if it is not still running
3. Click the Download icon (1
st
on the left) or select Data
Download from the LINK pull-down menu
4. The Window shown below will appear. Press DOWNLOAD to
begin transferring readings
