22
trace (Temperature, RH, Dew Point, & Alarms).
BACKGROUND: Select background color scheme.
GRID LINES: Add or remove grid lines from x and y axes.
MASK POINTS: Places dots on the traces for the actual data
points, breaking up the continuous nature of a trace.
Notes: The horizontal grid line will be aligned to specific values on
the temperature axis, while any alignment with specific values on
the relative humidity axis is merely coincidental.
SAVE AND OPEN DATA FILES
To save the transferred data in a format other than the proprietary
.rec format, click the SAVE AS icon from the menu bar (4
th
from
right) or select SAVE AS from the FILE pull-down menu. The data
can be saved in the following formats:
TEXT FILE (.txt)
EXCEL FILE (.xls)
BITMAP FILE (.bmp)
To open an existing data file for viewing on the data graph window,
click on the FILE OPEN icon on the menu bar (3
rd
from left) or
select FILE OPEN from the FILE pull-down menu. When prompted,
select a .rec file saved earlier.
