The top right-hand corner indicates what is to be

setup:

Pressing button 3(+) will toggle through:

- Syrup Flavours 1 to 4

- Soda Water

- Still water

Note:Thecarbonatedwaterowrateshouldbe

setrst,followedbythestillwaterandlastlythe

syrupowrates.

Soda / Still Flow Rate Test Pour:

Ensuring there is a cup under the dispense nozzle,

press button 4 once. The unit will dispense a 7

second pour of carbonated water or still water,

depending on which screen you are in.

Measure the volume dispensed, then adjust the

dispensevalveowrate.

See section below: Calculation of carbonated and

stillwaterow

Section 3

The Albi unit nished drink ow rate is typically designed to pour at 1.5oz/

sec. (42.5ml/sec.) @ 5:1 syrup ratio.

Thisisanexampleofhowtheowratesarecalculated:

((Flow rate per second / the total parts of the ratio) x (parts of the ratio for carb/still

water)) x 7 second pour

For1.5ozpersecondnisheddrink,@5:1ratio,thewaterowratecalculationis:

((1.5oz per sec. / 6 total ratio parts) x (5 parts of the ratio)) x 7 seconds = 8.75oz

(246ml)

Once the still water ow rate is set, now set the syrup ow rates:

Calculatethesyrupowvolumeforthe7secondtestpour:Examplecalculationfor

1.5ozpersecondnisheddrink,@5:1ratio:(1.5ozpersec./6totalratioparts)x7

seconds = 1.75oz (49.6ml)
